This week, the market people from my work wanted to put QR codes in shopping cart handles, but when they tested it, the QR code did not work. I noted that the cylindrical curvature (even small) distorted the image, and the cell phone can't read it.

diagram

Here is some test QR code:

qrCode

I thought that this would be a nice thing to do with Mathematica, to try to figure out how I could print the QR code into some way that when attached to the cylindrical form, it would be like a normal square, at least at some angles.

I tried to simulate how it would be plotted in the handle using Texture, and I get this:

qrCode = Import["http://i.stack.imgur.com/FHvNV.png"];
RevolutionPlot3D[{1, t}, {t, 0, 20}, Mesh -> None, PlotStyle -> Texture[qrCode],
                 TextureCoordinateScaling -> False, Lighting -> "Neutral", ImageSize -> 100]

cylinder with QR code

Here is some code from the docs for Texture that I tried to adapt, without success:

RevolutionPlot3D[{1, t}, {t, 0, 1}, PlotStyle -> Texture[qrCode], Mesh -> None,
                 TextureCoordinateFunction -> ({#3, #2} &), Axes ->  False,
                 Lighting -> "Neutral", ImageSize -> 300, AspectRatio -> 1]

texture

Does anyone know how I can distort the QR code, in a way? I believe that it's equivalent to projecting the texture onto the surface, and then using the projected image.

update: This problem is very similar to this, the difference is that we are in the cylinder, and this anamorphic illusion example is in the plane.

share|improve this question
2
This is a nice question. I believe guys doing street art in 3D kind of have the same problems ;-) –  halirutan Jun 2 '13 at 3:10
1
Related question. –  J. M. Jun 2 '13 at 3:13
1
Another, arguably related question: (5676) –  Oleksandr R. Jun 2 '13 at 5:25
5
I used Mathematica to find this i.stack.imgur.com/fZJe0.jpg –  belisarius Jun 2 '13 at 13:53
6
You should marry a package designer. My wife's response to this was, "The shopper's gotta work out just the right angle to photograph the code this way. Why not just introduce a little plastic structural element to make a flat enough surface for it? Something you can clip onto any shopping cart handle?" –  Fordi Jun 3 '13 at 1:24

2 Answers 2

up vote 141 down vote accepted

First of all: A comprehensive outline of the following idea without any mathematical formulas but with detailed explanations can be found here on on 2d-codes.co.uk or, if you happen to speak danish here on http://qrkoder.internet.dk/.

Teaser

The answer below works (with some modifications). Please click the image to see how the QR code projection looks, when the image is rotated:

enter image description here

And everything here can be used for real applications. At the end of this answer you'll find images of the QR code printed on a real cylinder. But applications are not restricted to this. You can easily adapt the approach to keep you up all night

red bull small 1

red bull small 2

The theory

Murta, you wrote

I thought that this would be a nice thing to do with Mathematica, to try to figure out how I could print the QR code into some way that when attached to the cylindrical form, it would be like a normal square, at least at some angles.

Exactly the viewpoint, more specifically the perspective projection, is crucial to determine how you have to transform your label so that it is squared again. Let me give an example where I drew something onto a paper-roll which obviously has nothing to do with the transformation used in bills answer:

enter image description here

If I now inspect this roll from a specific viewpoint it looks like a QR code should be recognized again:

enter image description here

The question is what happens here. The theory behind it is pretty easy and the good thing is, it explains what you have to do from any (meaningful) viewpoint. Let's use a simple cylinder graphic as example to explain what I mean

ParametricPlot3D[{Cos[u], v, Sin[u]}, {u, 0, 2 Pi}, {v, 0, 10},
 Boxed -> False, Axes -> False, ViewAngle -> .1,
 Epilog :> {FaceForm[None], EdgeForm[Red],
   Rectangle[{.4, .4}, {.7, .7}]}]

enter image description here

When you finally see the image on your screen, two transformations took place. First, ParametricPlot3D used my formula to transform from cylinder coordinates {u,v} into 3D Cartesian coordinates {x,y,z}. This transformation of the {u,v} plane can easily be simulated by sampling it with Table, doing the transformation to 3D by yourself and drawing lines

Graphics3D[{Line[#], Line[Transpose@#]} &@
  Table[{Cos[u], v, Sin[u]}, {u, 0, 2 Pi, 2 Pi/20.}, {v, 0, 10, .5}]
 ]

enter image description here

The next thing that happens is often taken for granted: The transformation of 3D points onto your final image plane you are seeing on the screen. This final ViewMatrix can (with some work) be extracted from a Mathematica graphics. It should work with AbsoluteOptions[gr3d, ViewMatrix] but it doesn't. Fortunately, Heike posted an answer how to do this.

Let's do it

OK, to say it with the words of Dr. Faust "Grau, teurer Freund, ist alle Theorie, und grün des Lebens goldner Baum". After trying it I noticed that the last two paragraphs of my first version are not necessary.

Let us first create a 3D plot of a cylinder, where we extract the matrices for viewing and keep them up to date even when we rotate the view.

{t, p} = {TransformationMatrix[
    RescalingTransform[{{-2, 2}, {-2, 2}, {-3/2, 5/2}}]],
   {{1, 0, 0, 0}, {0, 0, 1, 0}, {0, 1, 0, 0}, {0, 0, 0, 1}}};
ParametricPlot3D[{Cos[u], v, Sin[u]}, {u, 0, 2 Pi}, {v, 0, 10},
 Boxed -> False, Axes -> False, ViewMatrix -> Dynamic[{t, p}]]

Now {t,p} always contain the current values of our projection. If you read in the documentation to ViewMatrix, you see that

The transformation matrix t is applied to the list {x,y,z,1} for each point. The projection matrix p is applied to the resulting vectors from the transformation.

and

If the result is {tx,ty,tz,tw}, then the screen coordinates for each point are taken to be given by {tx,ty}/tw.

Therefore, we can easily construct a function from {u,v} to screen-coordinates {x,y}

With[{m1 = t, m2 = p},
  projection[{u_, v_}] = {#1, #2}/#4 & @@ (m2.m1.{Cos[u], v, Sin[u], 1})
]

Let's test wether our projection is correct. Rotate the cylinder graphics so that you have a nice view and execute the projection definition again.

Graphics[{Line /@ #, Line /@ Transpose[#]} &@
  Table[projection[{u, v}], {u, 0, 2 Pi, .1}, {v, 0, 10}],
 Axes -> True, PlotRange -> {{0, 1}, {0, 1}}]

enter image description here

Please note that this is no 3D graphics. We transform directly from {u,v} cylinder to {x,y} screen-coordinates. Those screen-coordinates are always in the range [0,1] for x and y.

Now comes the important step: This transformation can directly be used with TextureCoordinateFunction because this function provides you with {u,v} values and wants to know {x,y} texture positions. The only thing I do is, that I scale and translate the texture coordinates a bit so that the QR code is completely visible in the center of the image:

tex = Texture[Import["http://i.stack.imgur.com/FHvNV.png"]];
ParametricPlot3D[{Cos[u], v, Sin[u]}, {u, 0, 2 Pi}, {v, 0, 10},
 Boxed -> False, Axes -> False, ViewMatrix -> Dynamic[{t, p}],
 PlotStyle -> tex, TextureCoordinateScaling -> False,
 Lighting -> "Neutral",
 TextureCoordinateFunction -> (2 projection[{#4, #5}] + {1/2, 1/2} &)
]

Don't rotate this graphics directly, because although it uses specific settings for ViewMatrix, it jumps directly to default settings when rotated the first time. Instead, copy our original cylinder image to a new notebook and rotate this. The Dymamic's will make, that both graphics are rotated.

Conclusion: When I use the following viewpoint to initialize the view point

enter image description here

and then evaluate the projection definition line again and recreate the textured cylinder, I get

enter image description here

which looks as if I just added a QR code layer to the image. Rotating and scaling reveals that it is specific texture projection instead

enter image description here

Going into real life

When you want to create a printable version of this, you could do the following. Interpolate the QR code image and use the same projection function you used in the texture (note that I used a factor 3 and {1/3,0} inside ipf here. You use whatever you used as texture):

qr = RemoveAlphaChannel@
  ColorConvert[Import["http://i.stack.imgur.com/FHvNV.png"],
   "Grayscale"];
ip = ListInterpolation[
  Reverse[ImageData[qr, "Real"]], {{0, 1}, {0, 1}}];
ipf[{x_, y_}] := ip[Mod[y, 1], Mod[x, 1]];

With[{n = 511.},
 Image@Reverse@
  Table[ipf[3 projection[{u, v}] + {1/3, 0}], {u, -Pi, Pi, 2 Pi/n},
   {v, 0, 10, 2 Pi/n}]
]

Please note the Reverse since image matrices are always reversed and additionally, that I create now the image matrix for u from [-Pi,Pi]. This was a bug in the last version which created the back-side of the cylinder. Therefore, the perspective was not correct in the final result.

enter image description here

This can now be glued around a cylinder (after printing it with the appropriate height) and with the corrected print version, the result looks

enter image description here

awesome! Here from another perspective

enter image description here

share|improve this answer

Very cool real photo! In the first cylindric picture, how can I get the flat projected red square (or QR)? In some way I could use it as a texture again. Do you know how can I project and take the image back to reuse it? –  Murta Jun 2 '13 at 14:03
1
+1 For Goethe! (well and the rest ;-) –  user21 Jun 2 '13 at 17:32
3
Great work! Beautiful post! Thanks. –  Murta Jun 2 '13 at 19:10
3
I created a mathematica SE account just so I could upvote this answer. Well done, sir. –  Jason Jun 3 '13 at 16:57
2
@Jason, Welcome. You should stick around to see the amazing power of Mathematica on display here. –  RunnyKine Jun 3 '13 at 17:47

Here's a way to approach this. First import the QR coded image:

tag=Import["http://i.stack.imgur.com/SVKj3.png"]

In order to see what is happening, generate a regular grid

grid = Image[Plot3D[0, {x, 0, 1}, {y, 0, 1}, ViewPoint -> {0, 0, \[Infinity]},
           Lighting -> "Neutral", Boxed -> False, Axes -> False]]

enter image description here

and a mapping that stretches the grid in the proper way. The function needs to map within the unit square in such a way that it has derivative = 1 in the middle and stretches the grid at the top and bottom. One way to accomplish this is with an ArcTan:

h[x_] := (ArcTan[5 (x - 1/2)] + Pi/2)/Pi;
Plot[h[x], {x, 0, 1}]

enter image description here

The effect of the mapping on the grid is

ImageTransformation[grid, {#[[1]], h[#[[2]]]} &, {400, 600}]

enter image description here

to stretch the edges and leave the middle pretty much untouched (as is required). All that remains is to transform the tag itself:

 imgS = ImageTransformation[tag, {#[[1]], h[#[[2]]]} &, {400, 600}]

enter image description here

If you were to cut this out and wrap it around the handle of the shopping cart, it would be much squarer overall. Of course, it will be necessary to match the exact mapping to the proper diameter of the handle, and to be a bit more careful with the top and bottom edges.

Now for the horizontal bits (as discussed in the comments). Here's the tag parameterized onto the cylinder:

ParametricPlot3D[{Cos[theta], Sin[theta], rho}, {theta, 0, Pi}, {rho, 0, 2},
    PlotStyle -> Directive[Specularity[White, 30], Texture[tag]],
    TextureCoordinateFunction -> ({#1, #3} &), Lighting -> "Neutral",
    Mesh -> None, PlotRange -> All, TextureCoordinateScaling -> True,
    ViewPoint -> {0, 10, 0}, Boxed -> False, Axes -> False]

enter image description here

But what we need is to flip this around so that it bulges in rather than out... this is easily done by changing the mapping slightly:

ParametricPlot3D[{Cos[theta], -Sin[theta], rho}, {theta, 0, Pi}, {rho, 0, 2},
   PlotStyle -> Directive[Specularity[White, 30], Texture[tag]],
   TextureCoordinateFunction -> ({#1, #3} &), Lighting -> "Neutral",
   Mesh -> None, PlotRange -> All, TextureCoordinateScaling -> True,
   ViewPoint -> {0, 10, 0}, Boxed -> False, Axes -> False]

enter image description here

Now we want to combine the vertical and horizontal stretchings, so we can apply the same idea to the stretched image from above:

ParametricPlot3D[{Cos[theta], -Sin[theta], rho}, {theta, 0, Pi}, {rho, 0, 2},
   PlotStyle -> Directive[Specularity[White, 30], Texture[imgS]],
   TextureCoordinateFunction -> ({#3, #1} &), Lighting -> "Neutral",
   Mesh -> None, PlotRange -> All, TextureCoordinateScaling -> True,
   ViewPoint -> {0, 10, 0}, Boxed -> False, Axes -> False]

enter image description here

With a bit of luck, it should be possible to choose the mappings so as to work with the actual physical measurements of the shopping cart handle.

share|improve this answer

Very cool bill, but the horizontal distortion is necessary too. –  Murta Jun 2 '13 at 13:53

The above is just for the case where you look at it from straight on. But no reason you couldn't add another distortion function for the other direction in the same manner. –  bill s Jun 2 '13 at 13:58

@murta puzzled as to why horizontal distortion is necessary? You have to stand in one location - why not square on? –  cormullion Jun 2 '13 at 14:14
4
@cormullion even in the same location it's not ok. See this picture where I tried to illustrate it (red lines). Without horizontal distortion, the final result isn't a square. –  Murta Jun 2 '13 at 14:40

@murta ah I see! Could be worth adding to the question... –  cormullion Jun 2 '13 at 14:49
